R-FVE-DC2 IKA switchboard – protection class II

EAN: 8594217350239 SKU: R-FVE-DC2T2 IKA

DC switchboard designed for wall mounting, IP65, serves as an input switchboard from photovoltaic panels (to the inverter) for the entire portfolio of photovoltaic power plants. Especially when using other switchboards, also EATON IKA.

More information

Prices are visible only to registered users.

PRODUCT DESCRIPTION

Product description

The switchgear is equipped with a DC surge arrester with fuse disconnectors including gPV fuses to protect the DC input to the inverter.

Suitable for combination with switchboards for the AC part of the installation fitted in EATON IKA switchboards.

List of main components:

EATON IKA-1/18-ST switchboard, EATON SPPVT12-10-2+PE or EATON SPPVT2-10-2+PE surge arrester. EATON CHPV2U fuse-switch disconnectors including EATON PV15A10F gPV fuses.

A detailed list of components can be found in the documentation tab, along with schematics and all documentation.

Main parameters

Inverter type

All types of inverters

Other parameters

UV resistance	No
IP coverage	65/20
Number of strings	2

Inverter parameters

Inverter power (max. kW)	3.7kW
Inverter power (max. kW)	11kW
Inverter power (max. kW)	13.8kW
Inverter power (max. kW)	17.3kW
Inverter power (max. kW)	22.1kW
Inverter power (max. kW)	27.6kW
Inverter power (max. kW)	34.5kW
Inverter power (max. kW)	43.5kW
Inverter power (max. kW)	55.2kW
Inverter power (max. kW)	69.0kW
Inverter power (max. kW)	86.3kW
Inverter power (max. kW)	110.4kW
Suitable for hybrid inverters	Yes
Suitable for mains inverters	Yes

Inverter brands

Suitable for Growatt	Yes
suitable for Solis	Yes
Suitable for GoodWe	Yes
Suitable for DEYE	Yes
Suitable for Solax	Yes

Code	Manufacturer	Product	Description	Number of pieces
174200	EATON	IKA-1/18-ST	Switchboard ON IP65 plaster, transparent door, 1 row, 18 modules	1
176090	EATON	SPPVT2-10-2+PE	Surge arrester T2 (II, C), photovoltaic applications 1000V DC, max. short-circuit current 160A	2
2625085	EATON/ETI/OEZ	CH10x38 gPV 15A/1000V DC	Ultra-fast cylindrical fuse for photovoltaics, (UL standard), 10x38mm, 1100V DC, 15A	4
CHPV2U	EATON	CHPV2U	Fuse disconnector, photovoltaic applications, 2-pole, 1000V AC / 30A, C10 (10x38mm)	2
